The Flangelicious is a quite easy to build and great sounding Phaser. It is available in 2 variants, this here is the classic 4 knob version. The 4KNOBFLANGE version is offering controls for manual flanger frequency, Depth, Rate, and Resonance (Feedback).
A typical Flanger uses a lots of chips and parts, but as the Flangelicious is integrating a lots of circuitry in a single chip, it is much easier to build. The sound is still generated by an anolog BBD IC, in this case the MN3207.
This kit is a creation by electricdruid.net in cooperation with Musikding.de. If you have any problem with the content of the kits like mising or wrong parts, please contact Musikding (Klaus) at kontakt@musikding.de. For any technical problem relating to building this project, please contact Tom at www.electricdruid.net
Here´s the parts list: Parts List (BOM)
This kit contains all parts you need to build a fully functional effect pedal. Not included in the kit, but also good to have:
- Aluminium enclosure: select one from top
- 9V DC power supply
- 4 nice knobs for the potentiometer, up to 20mm diameter and for 6.3mm shafts
- Decal, transfer or transparent sheets for labeling
Here is the very detailed build document:
Flangelicious Build docs
Here´s the project page with further information:
Flangelicious project page
Sounds
The clis were played directly to desk, no additional amps or effects:
Chimes:
Funky:
Funky #2:
Rock:
Lead:
