GermanThe Electra - Distortion kit
Description
The Electra Distortion is a very Tweed-Amp sounding Overdrive/Distortion pedal. Due to its low part count it is also a good start for beginners!
This kit contains all parts you need to build a fully functional effect pedal.
Not included in the kit, but also very good to have:
- Aluminium enclosure: select one above.
- 9V battery or DC power supply
- 1 nice knob for the pot, for 6,3mm shaft
- Decal, transfer or transparent sheets for labeling
| Instrument: | Guitar |
| Effect-Type: | Amp-Sim Distortion Overdrive |
Build documents
Installation guide: Installation guide
Schematic and pcb: Schematic
Wiring layout: Wiring
Parts list (BOM): Parts list
